Suitable for Outdoor|Yes|Wired/Wireless|Wired|Interface(s)|1 x RJ45 10/100M Self-Adaptive Ethernet Port, PoE DC Power Port Memory Card Slot (MicroSD Card up to 512GB)|Image Sensor|1/2.9” Progressive Scan CMOS|Resolution|Main Stream: 2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080 Sub-Stream: 1280x720, 848x480, 704x576, 640x480, 640x360, 352x288, 320x240 |Frame Rate|Main Stream: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Sub-Stream: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps|Video Compression|Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264|Lens|Motorized Varifocal Lens Focal Length: 2.7-13.5 mm (5X Optical Zoom) Lens Mount: 14mm diameter Aperture: F1.6 DORI Distance: Detect: 66-207 m (217-579 ft) Observe: 28-86 m (92-282 ft) Recognize: 13-41 m (43-135 ft) Identify: 7-21 m (23-69 ft)|Viewing Angle|Horizontal FOV: 29.6°-102.0° Vertical FOV: 16.8°-53.8° Diagonal FOV: 34.1°-122.8°|Pan/Tilt/Rotation|Pan: 0° to 360° Tilt: 0° to 77° Rotation: 0° to 360°|Day/Night Mechanism|IR Cut Filter Day/Night Switch: Unified/ Scheduled/ Auto|IR Working Distance|IR LED Quantity: 4 Range: 60m (197ft) Wavelength: 850nm|Minimum Illumination|0.005 Lux; 0 Lux with IR Light|Video Streaming|Main Stream Sub-Stream|Image Settings|Mirror Brightness Contrast Saturation Sharpness Exposure WDR White Balance Prevent Overexposure to Infrared Light HLC Adjustable by Client Software|Audio Features|Two-Way Audio Audio Input Audio Output Audio Compression Audio Sampling Rate: 8KHz Environment Noise Filtering Audio Bit Rate: 64 Kbps(G.711 alaw) Built-in Microphone records anything within a 15ft radius|Alarm & Event Management|Smart Event Detection: Intrusion, Line-Crossing, Region Entering, Region Exiting, Object Abandoned, Object Removal, Loitering, People, Vehicle, Abnormal Sound, Scene Change Basic Event: Motion Detection (Enhanced with Human & Vehicle Classification) Video Tampering Detection Exception (Illegal Login) Linkage Method: Memory Card Video Recording Message Push Audible Warning Email Alarm Upload Capture to FTP Alarm Out Device|Network|Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP ONVIF: Yes API: Open Network Video Interface (Profile S/T/G) Simultaneous Live View: 3 Main Streams & 3 Sub-Streams Cloud: Yes|Wireless Features|-|Security|Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication|Management|VIGI App, VIGI Security Manager, Web UI, VIGI VMS, VIGI Cloud VMS|Power Supply|12V DC, Max.10.8 W, 5.5 mm Coaxial Power Plug PoE: 802.3af/at, class 0, Max.12 W|Additional Features|See Overview|Weight/Dimensions|0.71 kg 112.3 (diameter) x 92.5 mm|Environment|IP67 Waterproof Operating Temperature: -30–60 °C Storage Temperature: -40–60 °C Operating Humidity: 95% or Less (Non-Condensing) Storage Humidity: 95% or Less (Non-Condensing)|Package Contents|VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories|Package Weight|0.9400 kg|Warranty|5 Years|#Hide#Resolution|4MP
