Primary Function|Access Point|#Hide#Access Point Mode|Yes (Access Point Mode)|#Hide#Wireless Standard|802.11be (Wi-Fi 7)|Bands|Tri Band|Wi-Fi Rating|BE9300|Max Single Band Wi-Fi Rate|5760 Mbps|Max Wired Transfer Rate|2.5 Gbps|Interface(s)|1 x 2.5G Ethernet Port|Wireless Standards|IEEE 802.11 a/b/g/n/ac/ax/be|Antenna(s)|2.4 GHz: 2x 4.0 dBi 5 GHz: 2x 5.0 dBi 6 GHz: 2x 5.0 dBi|Button(s)|Reset|Power Supply|802.3at PoE or 12V/2.5A DC NOTE: Power Adapter is NOT included.|Power Consumption|24.05 W (For PoE) 20.92 W (For DC)|Dimensions|220 x 220 x 32.5 mm|Weatherproof|No|Frequency|2.4GHz: Up to 574 Mbps 5GHz: Up to 2880 Mbps 6GHz: Up to 5760 Mbps|Wireless Functions|MLO 4K-QAM Seamless Roaming(802.11k/v/r) MU-MIMO EHT320 Mesh BSS Coloring OFDMA Load Balance Band Steering Beamforming Airtime Fairness Multiple SSIDS:24(8 on each band) Wireless Schedule Reboot Schedule QoS(WMM) Rate Limit Static IP/Dynamic IP RADIUS Accounting MAC Authentication|Security|Captive Portal Authentication Access Control Maximum number of MAC Filter: 4,000 Wireless Isolation Between Clients VLAN Rogue AP Detection WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise|Management|Omada App Centralized Management Omada Hardware Controller (OC200 & OC300) Omada Software Controller Omada Cloud-Based Controller Cloud Access - Requires controller Email Alerts LED ON/OFF Control Management MAC Access Control SNMP: v1, v2c, v3 System Logging Local/Remote Syslog Web-based Management|Additional Features|See Overview|Environment|Operating Temperature: 0–40 °C (32–104 °F) Storage Temperature: -40–70 °C (-40–158 °F) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing|Package Contents|EAP772 Installation Guide Ceiling/Wall Mounting Kit Note: Power Adapter is NOT included.|Package Type|Retail|Package Weight|1.3400 kg|Warranty|Limited Lifetime
