Primary Function|Access Point|#Hide#Access Point Mode|Yes (Access Point Mode)|#Hide#Wireless Standard|802.11ax (Wi-Fi 6/6E)|Bands|Dual Band|Wi-Fi Rating|AX6000|Max Single Band Wi-Fi Rate|4804 Mbps|Max Wired Transfer Rate|2.5 Gbps|Interface(s)|1 x 2.5 Gigabit PoE+ Port|Wireless Standards|IEEE 802.11ax/ac/n/g/b/a|Antenna(s)|Internal Omni: 2.4 GHz: 4x 4 dBi 5 GHz: 4x 5 dBi|Button(s)|Reset|Power Supply|802.3at PoE 12V / 2A DC (Power Adapter IS NOT included)|Power Consumption|20.43W|Dimensions|220 x 220 x 32.5 mm|Weatherproof|No|Frequency|5 GHz: Up to 4804 Mbps 2.4 GHz: Up to 1148 Mbps|EIRP|<20 dBm(2.4 GHz, EIRP) <23 dBm(5 GHz, band1 & band2, EIRP) <28 dBm(5 GHz, band3, EIRP)|Wireless Functions|1024-QAM 4x Longer OFDM Symbol OFDMA Multiple SSIDs (Up to 16 SSIDs, 8 for each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) MU-MIMO (4*4 MU-MIMO DL&UL) MIMO [4*4 (2.4G and 5G) MU-MIMO; 4*4 (2.4G and 5G) SU-MIMO]|.|HE160 (160 MHz Bandwidth) Seamless Roaming(802.11k/v/r) Omada Mesh Band Steering Load Balance Airtime Fairness Beamforming Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client|Security|Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Rogue AP Detection 802.1X Support WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise|Wireless Range|Ultra-range wireless coverage|Management|Omada App Centralized Management Cloud Access Email Alerts LED ON/OFF Control Management MAC Access Control SNMP v1, v2c, v3 Local/Remote Syslog SSH HTTP/HTTPS L3 Management Multi-site Management Management VLAN Zero-Touch Provisioning|Additional Features|See Overview|Environment|Operating Temperature: 0–40 °C (32–104 °F) Storage Temperature: -40–70 °C (-40–158 °F) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing|Package Contents|EAP683 UR Ceiling/Wall Mounting Kits Installation Guide|Package Type|Retail|Package Weight|1.3000 kg|Warranty|Limited Lifetime
