Primary Function|Access Point|#Hide#Access Point Mode|Yes (Access Point Mode)|#Hide#Wireless Standard|802.11ax (Wi-Fi 6/6E)|Bands|Dual Band|Wi-Fi Rating|AX5400|Max Single Band Wi-Fi Rate|4804 Mbps|Max Wired Transfer Rate|2.5 Gbps|Interface(s)|1 x 2.5 Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)|Antenna(s)|Internal Omni: - 2.4 GHz: 2x 4 dBi - 5 GHz: 4x 5 dBi|Button(s)|Reset|Power Supply|802.3at PoE 12V/2A DC|Power Consumption|20.8W (For PoE) 18.5W (For DC)|Dimensions|220 x 220 x 32.5 mm|Weatherproof|No|Frequency|5 GHz: Up to 4804 Mbps 2.4 GHz: Up to 574 Mbps|Wireless Functions|1024-QAM 4x Longer OFDM Symbol OFDMA Multiple SSIDs (Up to 16 SSIDs, 8 for each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) MU-MIMO HE160 (160 MHz Bandwidth)|.|Seamless Roaming Omada Mesh§ Band Steering Load Balance Airtime Fairness Beamforming Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client|Security|Captive Portal Authentication§ Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Rogue AP Detection 802.1X Support WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise|Quality of Service|QoS(WMM)|Management|Omada App Centralized Management Cloud Access Email Alerts LED ON/OFF Control Management MAC Access Control SNMP: v1, v2c, v3 Local/Remote Syslog SSH Web-based Management: HTTP/HTTPS L3 Management Multi-site Management Management VLAN Zero-Touch Provisioning. Requiring the use of Omada Cloud-Based Controller|Additional Features|See Overview|Environment|Operating Temperature: 0–40 °C (32–104 °F) Storage Temperature: -40–70 °C (-40–158 °F) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing|Package Contents|EAP670 NEW Power Adapter Ceiling/Wall Mounting Kits Installation Guide|Package Type|Retail|Package Weight|1.7000 kg|Warranty|Limited Lifetime
