Primary Function|Access Point|#Hide#Access Point Mode|Yes (Access Point Mode)|#Hide#Wireless Standard|802.11ax (Wi-Fi 6/6E)|Bands|Dual Band|Wi-Fi Rating|AX3000|Max Single Band Wi-Fi Rate|2402 Mbps|Max Wired Transfer Rate|10/100/1000 Mbps|Interface(s)|Uplink: 1 x 10/100/1000 Mbps Ethernet Port Downlink: 3 x 10/100/1000 Mbps Ethernet Ports (One port supports PoE out, and the PoE out|Wireless Standards|IEEE 802.11ax/ac/n/g/b/a|Antenna(s)|2 Dual-Band Antennas 2.4 GHz: 2x 3 dBi 5 GHz: 2x 5 dBi|Protection|Reset, LED|Power Supply|802.3af/at PoE|Power Consumption|12W (802.3at PoE, PoE Out off)|Dimensions|143 x 86 x 42.6 mm|Weatherproof|No|Frequency|2.4 GHz and 5 GHz|EIRP|<20 dBm (2.4GHz, EIRP) <23 dBm (5GHz band1 & 2, EIRP) <26 dBm (5GHz band3, EIRP)|Wireless Functions|16 SSIDs (Up to 8 SSIDs on each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) Seamless Roaming§ Beamforming Rate Limit Load Balance Airtime Fairness|.|Band Steering Reboot Schedule Wireless Schedule RADIUS Accounting MAC Authentication Wireless Statistics Static IP/Dynamic IP|Security|Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients VLAN Rogue AP Detection 802.1X Support WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise|Quality of Service|QoS(WMM)|Management|Omada App Omada Hardware Controller (OC300) Omada Hardware Controller (OC200) Omada Software Controller Omada Cloud-Based Controller Cloud Access - Requires Controller Email Alerts LED ON/OFF Control Management MAC Access Control SNMP v1, v2c, v3 System Logging Local/Remote Syslog SSH Web-based Management: HTTP/HTTPS L3 Management Multi-site Management Management VLAN Zero-Touch Provisioning - Requires Cloud-Based Controller|Additional Features|See Overview|Environment|Operating Temperature: 0–40 °C (32–104 °F) Storage Temperature: -40–70 °C (-40–158 °F) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing|Package Contents|AX3000 Wall Plate WiFi 6 Access Point Installation Guide Mounting Kits|Package Type|Retail|Package Weight|0.4500 kg|Warranty|Limited Lifetime
