Primary Function|Access Point|#Hide#Access Point Mode|Yes (Access Point Mode)|#Hide#Wireless Standard|802.11ac (Wi-Fi 5)|Bands|Dual Band|Wi-Fi Rating|AC1200|Max Single Band Wi-Fi Rate|867 Mbps|Max Wired Transfer Rate|10/100/1000 Mbps|Interface(s)|Uplink: 1 x 10/100/1000 Mbps Ethernet Port Downlink: 3× 10/100/1000 Mbps Ethernet Ports (One port supports PoE OUT. The PoE OUT feature requires 802.3at PoE+ input and the maximum output is 13 W.)|Wireless Standards|IEEE 802.11a/b/g/n/ac|Antenna(s)|2 x Dual-Band Antennas 2.4 GHz: 2 4 dBi 5 GHz: 2 4 dBi|Button(s)|Reset|Power Supply|802.3af/802.3at PoE|Power Consumption|9.8 watts /24.4 watts (PoE Out Included)|Dimensions|143 x 86 x 20 mm|Weatherproof|No|Frequency|2.4 GHz and 5 GHz|Wireless Functions|16 SSIDs (8 SSIDs on each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control QoS(WMM) MU-MIMO Band Steering Beamforming Load Balance Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client|Security|Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Local LAN port based VLAN Rogue AP Detection 802.1X Support 64/128/152-bit WEP, WPA/WPA2-PSK, WPA/WPA2-Enterprise|Quality of Service|Yes|Management|Omada App Centralized Management Cloud Access Email Alerts LED ON/OFF Control Management MAC Access Control SNMP v1,v2c Local/Remote Syslog SSH HTTP/HTTPS L3 Management Multi-site Management Management VLAN|Additional Features|See Overview|Environment|Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5%~90% non-condensing|Package Contents|Omada AC1200 Wall Plate Access Point Installation Guide Mounting Screw|Package Type|Retail|Package Weight|0.3220 kg|Warranty|Limited Lifetime
