Primary Function|Access Point|#Hide#Access Point Mode|Yes (Access Point Mode)|#Hide#Wireless Standard|802.11n (Wi-Fi 4)|Bands|Single Band|Wi-Fi Rating|N300|Max Single Band Wi-Fi Rate|300 Mbps|Max Wired Transfer Rate|10/100 Mbps|Interface(s)|1 x 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in) 1 x Grounding Terminal 1 x Reset Button|Wireless Standards|IEEE 802.11a/n (with Pharos MAXtream disabled)|Antenna(s)|Built-in 13dBi 2x2 Dual-polarized Directional Antenna Beam Width: 45 (H-Plane) / 30 (E-Plane)|Protection|15KV ESD Protection 6000V Lightning Protection|Button(s)|Remote Reset Button|Power Supply|Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) Voltage range: 16-27VDC|Power Consumption|13 Watts Max |Dimensions|110 x 57 x 33.5mm|Weatherproof|Yes (Weatherproof)|Frequency|5.15~5.85GHz|Reception Sensitivity|802.11a (dBm): 54M -75, 48M -76, 36M -83, 6-24M -95 802.11n (dBm): MCS15 -73, MCS14 -74, MCS13 -76, MCS12 -80, MCS11 -83, MCS10 -88, MCS9 -90, MCS8 -93, MCS7 -73, MCS6 -74, MCS5 -76, MCS4 -80, MCS3 -83, MCS2 -88, MCS1 -90, MCS0 -93|Security|Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption SSID Broadcast Enable/Disable Multi-SSID with VLAN Tagging (AP mode only) Distance/ACK Timeout Setting Wireless MAC Address Filter|Wireless Range|System-level optimizations for more than 15km|Management|Discovery and Remote Management via Pharos Control application HTTP/HTTPS Web-based management System Log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server|Additional Features|See manufacturers link (next to product images)|Environment|Operating Temperature:-30C~70C(-22F~158F) Storage Temperature: -40C~70C (-40F~158F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing|Package Contents|Outdoor Wireless CPE 24V 1A Passive PoE Adapter Pole Mounting Straps AC Power Cord Installation Guide|Package Type|Retail|Package Weight|0.7900 kg|Warranty|2 Years
