Asus IPMI Expansion Card w/ Dedicated Ethernet Controller, VGA Port, PCIe 3.0 x1 & ASPEED AST2600A3 *OEM Packaging*
£88.43
Tax included
ASUS IPMI expansion card with dedicated Ethernet controller, VGA port, PCIe 3.0 x1 interface and ASPEED AST2600A3 chipset to provide the intelligence for IPMI architectures
IPMI 2.0 compliant Out-of-band and in-band remote management with ASPEED AST2600A3 chipset Sensor monitoring with notifications of potentially dangerous readings or failure Control and monitoring of up to 8 chassis fans BIOS and BMC firmware update via web console or Linux tool Monitoring of power supply unit voltage and temperature
Remote Management
This ASUS IPMI expansion card delivers a breakthrough remote management solution for motherboards that have overclocking capabilities but not an onboard baseboard management contr
Delivery policy(edit with the Customer Reassurance module)
Return policy(edit with the Customer Reassurance module)
Chipset|ASPEED AST2600A3|Interface|PCIe 3.0 x1|Internal RAM|System: 384MB
Video: 64MB|Internal ROM|64MB|Timers|32-bit Watchdog Timer|Features|Sensor monitoring & reporting when exceeding thresholds/failure
Fan and PSU monitoring and faillure alerting
IPMI 2.0 compliant
Cold boot
HTML5 Virtual Console (no Java)
SOL Support
SSH (SMASH 2.0) support
SNMP V3 Alerting
Update BIOS, BMC firmware via Web console or Linux tool
BIOS setting changing
Component Inventory Management
*Some of key features requires cable connection from this card to motherboard or PSU. For more details, please refer to user manual|Graphics|1 x D-sub supports max. resolution 1920 x 1200 @ 60 Hz|External Connectors|1 x D-Sub
1 x LAN (RJ45) port|Internal Connectors|8 x fan headers
1 x 6-pin PSU connector
1 x BMC header
1 x SPI header
1 x PM_BUS header
1 x USB 2.0 connector
1 x VGA header
1 x Panel header(links to PWR/RST header)
3 x Tr sensor headers
1 x BMC switch jumper
1 x VGA switch jumper
1 x LOC switch jumper
1 x BMC Indicator LED|Operating System|Windows 10 - 64 bit, Linux OS including Cent OS, Redhat, and Ubuntu|Accessories|1 x BMC cable
1 x SPI cable
1 x Power On/Off cable
1 x Reset cable
1 x USB 2.0 cable
1 x IPMI TPM ADAPTER
1 x User manual|Package Weight|0.3250 kg|Warranty|1 Year
No customer reviews for the moment.
ASUS IPMI expansion card with dedicated Ethernet controller, VGA port, PCIe 3.0 x1 interface and ASPEED AST2600A3 chipset to provide the intelligence for IPMI architectures
IPMI 2.0 compliant Out-of-band and in-band remote management with ASPEED AST2600A3 chipset Sensor monitoring with notifications of potentially dangerous readings or failure Control and monitoring of up to 8 chassis fans BIOS and BMC firmware update via web console or Linux tool Monitoring of power supply unit voltage and temperature
Remote Management
This ASUS IPMI expansion card delivers a breakthrough remote management solution for motherboards that have overclocking capabilities but not an onboard baseboard management contr
