Asrock Intel Arc A770 Phantom Gaming 16GB OC, 16GB DDR6, PCIe4, HDMI, 3 DP, 2200MHz Clock, 0dB Cooling, RGB, Overclocked
£243.16
Tax included
Chipset Manufacturer|Intel|Interface|PCI Express 4.0|Graphics Chipset|Intel Arc A770|Memory Size|16GB|Memory Type|DDR6|Memory Interface|256-bit|Core Clock|2200 MHz|Memory Clock|17.5 Gbps|Intel XMX Engines|512|Outputs|1 x HDMI 2.1
3 x DisplayPort 2.0 up to UHBR 10|HDCP Support|Yes|Resolution|Digital Max Resolution: 7680 x 4320|DirectX Support|DirectX 12 Ultimate|Max Display Support|4|Cooling|Striped Axial Fan
Ultra-fit Heatpipe
0dB Silent Cooling
Copper Base
High-density Metal Welding|PSU Requirements|700W or greater recommended|Connectors Required|2 x 8-pin power|Software|Intel Arc Control software|Additional Features|See Overview|Dimensions| 305 x 131 x 56 mm|Slot Size|2.8 Slot|Accessories|1 x Quick Installation Guide|Package Type|Retail|#Hide#Lighting Effects|Yes|#Hide#HDMI|Yes (HDMI)|#H
Delivery policy(edit with the Customer Reassurance module)
Return policy(edit with the Customer Reassurance module)
Intel Arc A770 Phantom Gaming 16GB OC
- GPU Clock: 2200 MHz
- Memory Clock: 17.5 Gbps
- Intel® Arc™ A770 Graphics
- 16GB 256-bit GDDR6
- Intel® Xe HPG Microarchitecture
- Intel® Xe Super Sampling (XeSS)
- DirectX® 12 Ultimate
- 2 x 8-pin Power Connectors
- 3 x DisplayPort™ 2.0 / 1 x HDMI™ 2.1
- Polychrome SYNC
- Phantom Gaming 3X Cooling System
- Stylish Metal Backplate
- Striped Axial Fan
- Ultra-fit Heatpipe
- 0dB Silent Cooling
- Super Alloy Graphics Card
OC Edition
Great Performance.
Delivers great performance which is higher than reference cards based on the solid hardware design.
For Cool and Silent.
Phantom Gaming 3X Cooling System
For Cool and Silent.
Crafted for the best balance between the thermal efficiency and silence by all the details.
Ultra-fit Heatpipe
Consolidated to Maximize the Contact.
Ultra-fit Heatpipe
Consolidated to Maximize the Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
Maximize GPU Contact Area.
Copper Base
Maximize GPU Contact Area.
With premium copper base heatsink design, the direct contact area to the GPU would be maximized to improve thermal transfer effectively.
Improve Heat Dissipation.
High-density Metal Welding
Improve Heat Dissipation.
Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
Perfect Thermal Teamwork.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Better Heat Transfer.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Optimized Mounting Pressure.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
Spin For Cooling, Stop For Silence.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Create your own unique colorful light effects.
Polychrome SYNC
Create your own unique colorful light effects.
With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
Solid, Fancy, Cool.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
Super Alloy Graphics Card
Premium 100A Power Choke
2oz Copper PCB
Matte Black PCB
Super Alloy Graphics Card
SPS (Smart Power Stage)
Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the GPU with enhanced performance and OC capability.
Premium 100A Power Choke
Compared to traditional chokes, ASRock’s premium 100A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.
2oz Copper PCB
Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking.
Matte Black PCB
A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
Supercharge your gaming.
Dive into immersive, high-performance gaming with AI-enhanced XeSS upscaling and full support for DirectX* 12 Ultimate.
Experience immersive high-performance gaming.
Intel® Arc™ Control gives gamers options and controls to refine their gaming experience in an intuitive and modern layout. Get seamless driver updates, optimize your favorite games, stream from your home without interruption and more.
Xe Super Sampling (XeSS)
Take your gaming experience to the next level with AI-enhanced upscaling technology, enabling more performance with high image fidelity.
DirectX* 12 Ultimate Support
Fully compatible with the latest breakthroughs in graphics technologies, including ray tracing, variable rate shading, mesh shading and sampler feedback - the fundamentals for next-gen gaming.
Unleash your creativity.
Unleash your creativity.
Experience cutting-edge AI-accelerated content creation.
With industry-first AV1 hardware encode and the advanced Intel® Xe Media Engine, the most comprehensive media capabilities1 are at your fingertips.
Take center stage.
Broadcast seamlessly with advanced streaming technologies enabled by Intel® Arc™ Control software.
Elevate your gaming experience.
Refine your gaming experience with Intel® Arc™ Control in an intuitive and modern layout. Get seamless driver updates and optimize many of your favorite games.
Maximize your Intel® platform.
Enhance your creation, gaming and streaming experiences with Intel® Deep Link Technology features by pairing Intel® Core™ processors with Intel® Arc™ graphics.
21 Items
Data sheet
- Digital Max Resolution
- 7680 x 4320
Specific References
- EAN13
- 4710483943546
- MPN
- 90-GA4KZZ-00UANF
